We have two dogs and three cats. Long ago we gave up on the idea of using a normal sized water bowl and switched to a large salad bowl. This wasn’t ideal for a variety of reasons, including aesthetics, so we recently swapped it out for a decorative fountain in the corner of our kitchen.
This has been going great and with it’s 7 gallon capacity has let us go as long as a week between refills. The downside is it’s easier to forget to refill it when it doesn’t need to be done as often. Coupled with most of the water being stored in the base, you can’t tell it’s getting low at a glance as you walk by.
Technology to the rescue!
I installed a liquid level sensor manufactured by Milone Technologies purchased from Adafruit. If you go this route, note that the enclosed models aren’t just the eTape in a tube, they include a resistance to variable voltage board with a small MCU operating at 5V. I’m sampling this from an Adafruit HUZZAH32, an ESP32 based board running at 3.3 V. According to the data-sheet, a 3.3 voltage from the 12" eTape is around 9". In my case, this would be overflowing so I can read the voltage directly, if that doesn’t work in your situation, you’ll need a voltage divider to bring the max value below 3.3. The data-sheet also says the sensor needs a minimum of 6 volts to run but I haven’t had any trouble running it from the 5 V USB pin on the HUZZAH32.
My source code for the ESP32 is on Github but I’ve reproduced the important bit here:
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
The top of the water in the base of the fountain is rather turbulent with constant water splashing down as it drains from the base so we do some averaging. We take a few readings one second apart and average those. We then average that reading with the readings over the last few minutes and fire it off to MQTT for use in Home Assistant.
Home Assistant Configuration
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Of course the real win of Home Assistant is using automations.
1 2 3 4 5 6 7 8 9 10 11 12 13
Our evening voice notifications come around 6:30pm when we are likely to hear
script.notify_tts_all_t sends a push notification to my wife and my
phones, speaks the notification on Google Home and Alexa speakers throughout
the house, and posts a tweet on my house’s twitter account. The source for that script as well
as the rest of my Home Assistant config is available on Github.
